China Hot SaleJS1000 Concrete MixerJS2000 2000L Twin shaft concrete mixer is currently an advanced and ideal model at home and abroad, with advantages such as high automation, good mixing quality, high efficiency, low energy consumption, low noise, convenient operation, fast unloading speed, l
China Hot Sale JS1000 Concrete Mixer
JS2000 2000L Twin shaft concrete mixer is currently an advanced and ideal model at home and abroad, with advantages such as high automation, good mixing quality, high efficiency, low energy consumption, low noise, convenient operation, fast unloading speed, long service life of lining plates and blades, and convenient maintenance. This machine adopts an automatic discharge method, and the whole machine has the advantages of convenient water addition control, strong power, low power consumption, and strong power. In addition, it is equipped with a built-in eddy current mixer to prevent material agglomeration in the silo.
The mixer mainly consists of mixing drum, hopper, mixing blades, mixing shaft, mixing arm, frame, unloading mechanism, oil supply, water supply system, and electrical system.
① Mixing system: High alloy wear-resistant material, uniform and stable mixing.
② Unloading system: divided into hydraulic control, pneumatic control, and manual control.
③ Electrical system: equipped with short-circuit protection and overload protection functions, safe and reliable, easy to operate and maintain.
④ Water supply system: The throttle valve can adjust the flow of water, the total water supply is regulated by a time relay.
⑤ Lubrication system: Adopting electric pump centralized oil supply lubrication, fully automatic grease lubrication, high grease pressure, high viscosity, and low oil consumption.
⑥ Sealing system: Multiple shaft end sealing protection technology, no slurry leakage.
Convenient transportation, crawler walking, no damage to the road, equipped with multi-functional accessories, Drived by oil and electricity.
The whole crushing plant adopts all-wheel drive to realize rotating direction in place, with perfect protection function, especially suitable for narrow and complex site.
The crawler crushing plant could be optional for jaw crusher, impatct crusher, cone crusher, VSI crusher etc.
It can work uphill to meet the crushing requirements of mining, hydropower station, coal mine and other projects.
JS2000 concrete mixer Mixing system
The mixing system is composed of an electric motor, a pulley, a speed reducer, an open gear, a stirring drum stirring device, an oil supply device and the like. The motor is directly connected to the cycloidal pin reducer, and the two output shafts of the reducer are driven by two pairs of open gears to rotate the two horizontally arranged stirring shafts at the same speed.
JS2000 concrete mixer Feeding system
The feeding system is composed of a hoisting mechanism, a feeding dragon frame, a hopper, a feeding nozzle and the like. The brake motor drives the reel to rotate through the reducer, and the wire rope climbs along the loading rack rail through the pulley pulling hopper. When climbing to the preset height, a pair of rollers on the bottom door of the hopper enters the water rail of the loading rack, and the bucket door automatically opens. The material is fed into the mixing drum through the feed nozzle.
JS2000 concrete mixer Discharging system
The unloading system consists of unloading door, air pump, reversing valve, air valve, cylinder, electrical and other mechanisms.The discharge door is at the bottom of the mixer, and the pneumatic discharge and the opening and closing position of the discharge door are controlled by the cylinder. The position of the sealing strip can be adjusted to ensure the sealing of the discharge door. The unloading manual operating lever of JS1500 concrete mixing station is used for emergency unloading during temporary power failure and cylinder failure. It should be removed in peacetime to prevent injury.
JS1500 concrete mixer Electrical System
The electrical circuit of JS2000 concrete mixer has air switch, fuse, thermal relay, short circuit protection and overload protection. Control buttons and air switch handles and indicators are located on the distribution box door and have a door lock. There is a protective cover on the button.
*The output will vary according to different materials, feed particle size and other factors
